Product Introduction

PRODUCT
Based on the CUDA parallel high-speed computing framework, the company has developed conventional algorithms and AI model inference algorithms. By integrating multiple algorithms, these solutions are compatible with 8K monochrome cameras, 8K color cameras, 16K ultra-high-definition monochrome cameras, 16K ultra-high-definition color cameras, and line scan cameras. Combined with multi-specification intelligent light source technology, stroboscopic technology, and interference-free 10G fiber optic transmission technology, they enable 3D imaging, color imaging, and ultra-high-definition imaging of material defects, ensuring efficient and accurate defect detection.
The system is capable of inspecting both coiled and sheet materials (including irregular-shaped ones), and is applicable to advanced manufacturing fields with stringent detection requirements such as semiconductors, new energy, papermaking, films, metals, electronic materials, and hygienic materials, delivering optimal solutions for customers.
/uploadfile/202511/cca45cda1008.png

Technical Parameters

PARAMETER
Industry Camera Accuracy Speed (max) Line Rate (max)
Hygienic Materials 8K Monochrome & Color 0.1~0.15mm/pixel 600m/min 100000line/sec
New Energy Materials 8K & 16K Monochrome 0.1~0.05mm/pixel 250m/min 84000line/sec
Optical Materials 8K & 16K Monochrome 0.1~0.045mm/pixel 350m/min 130000line/sec
Electronic Materials 8K & 16K Color 0.015~0.05mm/pixel 30m/min、80m/min 34000line/sec
Packaging Materials 8K & 16K Monochrome 0.1mm/pixel 650m/min 109000line/sec
Metal Materials 8K Monochrome & Color; 16K Monochrome & Color 0.025~0.05mm/pixel 60m/min、180m/min 60000line/sec
